| Avialable Models (see charts below for details) |
| TouchStream LE |
TouchStream LE SDI |
TouchStream LE HDI |
| TouchStream Web |
TouchStream Web SDI |
TouchStream Web HDI |
| TouchStream Mobile |
TouchStream Mobile SDI |
TouchStream Mobile HDI |
| TouchStream TS |
TouchStream TS SDI |
TouchStream TS HDI |
| Options |
| Professional Carry Bag |
| Archive storage (CompactFlash adapter, internal hard drive, removable hard drive) |
| Inputs |
Analog models |
SDI models |
HDI models |
| Composite analog video |
• |
o |
|
| Y/C (S-Video) analog video |
• |
o |
|
| Balanced analog audio (XLR) |
• |
o |
|
| Unbalanced analog audio (RCA) |
• |
o |
|
| Component analog video |
• |
o |
|
| SDI video |
|
• |
HD/SD |
| Embedded SDi audio |
|
• |
• |
| AES/EBU stereo audio (XLR) |
|
o |
o |
| Audio processing channels (stereo) |
2 |
4* |
4 |
| Input video frame formats |
480i (NTSC),
576i (PAL) |
480i
(NTSC),
576i (PAL) |
SD:
480/486i
(NTSC),
576i (PAL)
HD-compatible:
1080i,1080p,720p**
|
| Input Options |
| Optional breakout cable or box required for analog and AES/EBU with TouchStream SDi |
| Optional breakout box required for AES/EBU inputs with TouchStream HDI |
| Output Formats (by model) |
LE |
Web |
Mobile |
TS |
| VC-1/Windows Media (Microsoft Silverlight incl. Smooth Streaming) |
• |
• |
|
|
| H.264/AVC (Adobe Flash incl. Dynamic Streaming) |
|
• |
|
|
| H.264/AVC (Microsoft Silverlight incl. Smooth Streaming) |
|
• |
|
|
| H.264/AVC (e.g. to Darwin Server for QuickTime) |
|
• |
|
• |
| H.264/AVC for Apple iPhone/iPad with integrated segmenting*** |
o |
o |
o |
o |
| On2 VP6 (Adobe Flash) |
o |
o |
|
|
| AAC Audio |
|
• |
• |
• |
| MP3 Audio |
|
• |
|
|
| 3GPP (H.263, H.264, MPEG-4 Part 2, AAC and AMR audio) |
|
|
• |
|
| H.264/AVC in Transport Stream |
o |
o |
o |
|
| MPEG-2 in Transport Stream (live and file) |
|
|
|
|
| MPEG- 2 (file archiving only) |
o |
o |
o |
• |
| Features |
| Dimensions (screen not titled) |
400.5mm / 15.8"L
224.5MM / 8.84"w
142.5MM / 5.61"h (with feet on)
132.5mm / 5.22"H (feet off - 3RU)
|
Hardware-based video pre-processing
(motion adaptive de-interlacing, noise reduction, cropping, scaling, filtering, video adjustments)
|
•
|
| Graphic overlay |
•
|
| Manual start/stop, scheduling and GPI triggers |
• |
| Customizable, password-protected function locking |
• |
| Archive to file during streaming |
With optional internal or external
(USB) storage
|
* 2 stereo SDI embedded channels; 4 stereo channels with analog/AES option (2 SDI/AES + 2 analog, or 4 analog)
** HD inputs may require down-conversion (automatically performed within TouchStream) to lower resolution or frame rate for streaming output (dependent on output format.)
*** HTTP-based segmented streaming for iPhone/iPad requires optional internal or external storage
|
